Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine

1 Set/Sets
MOQ
negotiable
Prijs
Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Product name: Water Well Drilling Rig, Water Well Drilling Machine
Name: Water Well Drilling Equipment
Power Type: Diesel
Engine: Yunnei
Power(w): 60KW
Drilling depth: 180m
Drilling diameter: 130-254mm
Mud Pump (Recommended): BW160/10
Elevating capacity: 12 Ton
Rotary Torque: 3200-4600 N.m
Rotary Speed: 45-65rpm
Travelling speed: 2.5km/h
Climbing Ability max: 30°
Drill rod length: 1.5m, 2.0m, 3.0m
Drill rod diameter: 76mm/89mm
Application: water well drilling rig,agricultural irrigation wells
Feature: High Drilling Efficiency,Hydraulic Controlling,Multifunctional
Usage: Water Well
Type: Rotary Drilling Rig
After-sales service provided: Video technical support
Condition: New
Warranty: 1 Year
Weight: 4500 KG
Dimension(l*w*h): 3800*1500*2200mm
Markeren:

waterputboorapparaat

,

De Installatie van de de Putboring van het kruippakjewater

,

de hydraulische machine van de boorgatboring

Basis informatie
Place of Origin: Zhejiang, China
Merknaam: Sanrock
Certificering: CE ISO 9001:2015
Model Number: SR180K
Betalen & Verzenden Algemene voorwaarden
Packaging Details: Nude package for machines; Wooden package for spare parts; Or customer demand;
Delivery Time: 12-20days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Productomschrijving

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 0

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 1

Kenmerken
1Dit model van de boormachine maakt gebruik van een volledige hydraulische besturing en van de top aandrijving om de rotatie van de boorwerktuigen met een zeer hoog boorefficiëntie te besturen.
2Een redelijke algemene lay-out maakt gebruik van het op een trekker gemonteerde of volledig op de grond gemonteerde chassis voor vervoer met een goede manoeuvreerbaarheid.
3.zeer flexibel op moeilijke wegen en kan op grote schaal worden gebruikt op vele gebieden, zoals hulpbrononderzoek van hydrologische putten, kolenbed methaan, de ondiepe laag schaliegas, aardwarmte, enz.,en kan ook worden gebruikt voor reddingsactiviteiten in de kolenmijngaswinning.
4.De bovengemonteerde aandrijfkop heeft een grote drijfdiameter, geschikt voor vele soorten bouwwerkzaamheden, zoals slurrybooringen, luchtbooringen en luchtschuimbooringen,de eisen voor het boren van putten in verschillende terreinlagen te voldoen.

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 2

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 3Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 4

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 5



Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 6

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 7Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 8

Deze serie waterputboormachines is geschikt voor het boren van waterputten, irrigatieputten voor landbouwdoeleinden, geothermische boorputten voor airconditioning en boorputten voor andere doeleinden.met name van toepassing op wateropnameprojecten in bergachtige gebieden en op rotslagen.





Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 9



Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 10Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 11Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 12

Beschrijving van de producten

Productnaam Boormachine voor waterputten
Naam Waterboringsapparaat
Vermogensoort Diesel
Klimvermogen max. 30°
Boringdiameter 130-254 mm
Boordiepte 180 meter
Motormodel Yunnei
Vermogen ((w) 60 kW
Werkdruk 1.7-2.5Mpa
Roterende koppel 3200-4600 N.m.
Rotatiesnelheid 45 tot 65 tpm
Liftcapaciteit 12 ton
Toepassing waterputboorapparaat,landbouw irrigatieput
De lengte van de boorstaaf 1.5m, 2.0m, 3.0m
De diameter van de boorstaaf 76 mm/89 mm
Reissnelheid 2.5 km/u
Afmeting ((L*W*H) 3800*1700*2250 mm
Gewicht 4500 kg




Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 13Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 14Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 15

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 16Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 17Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 18



Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 19

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 20

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 21

Profiel van het bedrijf

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 22

Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 23



Crawler waterput boormachine hydraulische boorgat boormachine waterput boormachine 24

1Wat kun je van ons kopen?
DTH-boormachine, kernboormachine, snelwegboormachine, zonneboormachine, ankerboormachine, roterende boormachine, top hammer boormachine, ondergrondse jumbo boormachine, DTH-hamer, boorstaaf,schroefluchtcompressorWaterboorinstallatie, waterboorinstallatie voor vrachtwagens, schroefluchtcompressor, zuigerluchtcompressor, pneumatische rotsboor, boorstuk, trikonstuk, reserveonderdelen.

2Hoe kan ik betalen?
A: U kunt betalen met creditcard, TT, Western Union, LC etc.

3Hoe gaat het met de zending?
A: Voor grote hoeveelheden of zware producten verzenden we per zee of over land. De efficiëntie van de verzending hangt af van het land en de stad waarnaar u wilt verzenden. Voor kleine en delicate producten verzenden we per DHL,UPS, Fedex of TNT. U kunt ook de verzendmethode bepalen die u wilt voordat we verzenden.

4Hoe gaat het met de kwaliteitscontrole?
A: We hebben onze eigen ervaren QC. Er zal strenge inspectie en testen voor elke bestelling voordat ze worden verzonden.
