Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale

1 set/sets
MOQ
negotiable
Prijs
Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Product Name: de installatie van de kruippakjeboring
Vermogen ((w): 3.8KW
Vermogenstype: Diesel
Boordiepte: 20 tot 30 meter
Boringdiameter: 50-115 mm
Gradeerbaarheid: 35°
Schommel hoek: 13°
Hoeveelheid lucht: 15-25 m3/min
Roterende Torsie: 365 N.m.
Luchtverbruik: 16m ³ /min
Werkdruk: 1.0mpa
Hydraulische tankcapaciteit: 55L
Rotatiesnelheid: 380 tpm
Maximale voortstuwing: 11KN
Applicatie: Mijnbouw, steengroeve, het gat van de boringsontploffing, mijnbouw en bouw
Reissnelheid: 3.5Km/h
kenmerk: Hoge Boringsefficiency, Concurrerende Prijs
afmeting (l*w*h): 5777*2210*1942 mm
Gewicht: 5400 kg
Type: roterende boormachine
boorstaaf: T38, T45*3050/3660mm
Voerslag: 3980mm
Markeren:

Separated DTH Drilling Machine

,

Down The Hole Crawler Drilling Rig

,

DTH Drilling Rig
Basis informatie
Plaats van herkomst: Zhejiang, China
Merknaam: Sanrock
Certificering: CE ISO 9001:2015
Modelnummer: SPC300T Aanpassing
Betalen & Verzenden Algemene voorwaarden
Verpakking Details: Naakte verpakking voor boorplatform; houten verpakking voor reserveonderdelen; of op vraag van de kl
Levertijd: 18-25 werkdagen
Betalingscondities: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Levering vermogen: 3000 sets per maand
Productomschrijving

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 0Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 1

A pneumatic ground drilling rig is a robust and versatile piece of construction equipment designed for efficient drilling operations in soil, rock, and other subsurface materials. Powered by high-pressure compressed air, this machinery utilizes pneumatic energy to drive rotary or percussive drilling mechanisms, enabling precise and rapid penetration into the ground.
Built with durable alloys and corrosion-resistant components, it ensures reliability in harsh environments while minimizing maintenance requirements.
Widely employed in mining, civil engineering, and environmental projects, this rig delivers high torque-to-weight performance and operational flexibility across diverse geological conditions.



Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 2









Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 3



Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 4

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 5

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 6

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 7

Products Description

Product name
Drilling Rig
Model
SPC300D
SPC300T
Dimension
6100*2200*2105mm
5777*2210*1942mm
Min.Ground Clearance
250 mm
250mm
Weight
5400 kg
5400kg
Travel Speed
0-3.5 km/h
0-3.5km/h
Travel Motor Power
8.8 kW x2
8.8 kW x2
Gradeability
35°
35°
Swing Angle
13°
13°
Rotary Head Power
3.7kw
3.8kw
Rotary Torque
2000 Nm (at 0.7 MPa)
365N.m
Max.Rotary Speed
70rpm
380rpm
Air Consumption
1.73 m³/min at 0.3Mpa
16m³/min at 0.55Mpa
Max.Air Pressure
2.5MPa
1.0Mpa
Air Quantity
15-25 m3/min
15-25m³/min
Drill rod
φ76,φ89 X3000 mm
T38, T45*3050/3660mm
Hydraulic tank capacity
18L
55L
Feed stroke
3980 mm
3980mm
Maximum forward thrust
11KN
11KN
Sliding frame swing
left 47°/right 54°
Left 47°/Right 54°
Drill boom tilt
Up 46°/Down 23°
Up 46°/Down 23°
Drill boom swing
Left 40°/Rght 40°
Left 40°/Right 40°




Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 8

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 9

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 10Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 11

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 12

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 13

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 14Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 15

Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 16Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 17
Company Profile
Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 18
Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 19


Down The Hole Drilling Machine Separated DTH Drilling Rig Crawler Drilling Rig for sale 20
1.What can you buy from us?
Tunneling Jumbo drilling rig ,DTH drilling rig,Automatic drilling rig with rod changing system,rotary drilling rig,pile driver machine, core drilling rig ,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,Tricone bit ,eccentric casing system,DTH hammer,drill rod,spare parts etc.

2.How can I make payment?
A: You can pay directly online on Alibaba with credit card, or TT, Western Union, LC etc.

3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.

4.How is your quality control? A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.

5.Do you have any certificate of authorization?
A: Our machinery is CE certified.
